GDM47-125 (NC125) series molded case circuit breaker has high breaking capacity and current limiting characteristics, and isolation switch function. It can also assemble leakage protection accessories and can be combined with various electrical auxiliary devices to form functional switches. Used as an overload and short circuit protection in low-voltage distribution systems, it is suitable for isolation. The rated working voltage of the circuit breaker is AC230V (1P), AC400V (2P, 3P, 4P).

Comply with the IEC1009-1、GB/T 14048.2 Standard

Frame Size：125A

Current Grade：63-125A

Switching Capacity：Icn=10 kA

Poles： 1P、2P、3P、4P
